Phoenix Contact FLT-SEC-ZP2-3C-255/1
6 items in stock at supplier
Product details
The FLT-SEC-ZP2-3C-255/1 surge arrester from Phoenix Contact is a highly advanced protection device specifically designed for 3-phase power supply networks. It meets the requirements of lightning protection classes III and IV, providing effective protection against surges caused by lightning strikes or other electrical disturbances. With a test class of Type 1, this combined arrester is capable of handling high lightning impulse currents of up to 12.5 kA. The FLT-SEC-ZP2-3C-255/1 is suitable for mounting on 40 mm busbar systems and combines the functions of neutral conductor (N) and protective conductor (PE) in a single device, simplifying installation and saving space. With a protection level of only 1.5 V, it offers reliable protection for connected devices and systems.
- Suitable for 3-phase power supply networks
- Combined neutral and protective conductor for simplified installation
- Maximum lightning impulse current of 12.5 kA
- Protection level of only 1.5 V for optimal device protection.
Surge protection type | Lightning current arrester |
Number of conductors | 3 x |
Test class | Type 1 |
Item number | 33244524 |
Manufacturer | Phoenix Contact |
Category | Surge protection |
Manufacturer no. | 1168946 |
Release date | 17.5.2023 |
Surge protection type | Lightning current arrester |
Number of conductors | 3 x |
Lightning impulse current | 12.50 kA |
Rated leakage surge current | 20 kA |
Nominal voltage | 230 V |
Protection level | 1.50 V |
Test class | Type 1 |
Protection type (IP code) | IP20 |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 0.27 m |
Width | 0.11 m |
Height | 0.04 m |
