The GX4816 is a 96 kHz audio expander that provides remote expansion with a high number of inputs for SQ, Avantis, and dLive mixing systems, as well as for AHM audio matrix processors.

48 Microphone Preamps

+60 dB gain, phantom power indicators, and -20 dB pad for line-level sources.

16 Line Outputs

Balanced, relay-protected line outputs on XLR.

DX Connections

A pair of DX ports allows for the connection of additional DX expanders or the ME Personal Monitoring System (not available for dLive or AHM).

Plug-and-Play

No configuration required, simply connect to the mixer and you're ready to go. Firmware updates are automatically performed by the mixer.

Massively Expand Your System I/O!

Each GX4816 is equipped with 48 dLive microphone preamps with independent phantom power LED indicators, as well as 16 XLR line outputs. Additionally, there are 2 DX ports for connecting up to 4 DX expanders for further I/O expansion.

Maximum Flexibility

Place it where you need it. The GX4816 can be positioned up to 100 meters away from the mixer to ensure maximum flexibility in placement and features built-in rack ears for mounting in a 5U 19" space.
