Eaton impulse switch Z-S12/WW Manufacturer :Eaton Designation :Impulse switch 12AC, 2W, 16A, 50Hz Type :Z-S12/WW Function :other Mounting type :DIN rail Width in pitch units :2 Installation depth :60 mm Number of contacts as changeover contacts :2 Control voltage 1 :12 V Control voltage type 1 :AC Frequency of control voltage 1 :50 Hz Control voltage 2 :0 V Control voltage type 2 :AC Frequency of control voltage 2 :0 Hz Rated switching current :16 A Supply voltage :240..415 V Voltage type of supply voltage :AC Max. Incandescent lamp load :0 W Max. Fluorescent lamp load :0 VA Max. Fluorescent lamp load (duo circuit) :0 VA Max. Fluorescent lamp load (parallel compensated) :0 VA Max. Max. switching current (cos phi 0.6) :0 A Suitable for manual operation :yes Eaton impulse switch Z-S12/WW: more details Impulse switch, control voltage 12V 50Hz, function: 2 changeover contacts, rated current at 250V AC to IEC/EN 60669-2-2: 16A, cap installation dimension 45mm, installation width 2TE (35mm), top-hat rail mounting, terminal cross-section 0.5-10 qmm solid and stranded / 0.5-6 qmm flexible with wire end ferrule , EAN: 4015082653170.
