Finder installation relay 22.23.9.012.4000
Manufacturer: Finder
Designation: Installation relay
Type: 22.23.9.012.4000
Function: Mechanical
Mounting type: DIN rail
Width in units of pitch: 1
Installation depth: 58.4 mm
Number of contacts as normally open: 1
Number of contacts as normally closed: 1
Control voltage 1: 12 V
Control voltage type 1: DC
Frequency of control voltage 1: 0 Hz
Rated current: 20 A
Supply voltage: 12 V
Voltage type of supply voltage: DC
Max. incandescent lamp load: 1000 W
Max. fluorescent lamp load: 400 VA
Max. fluorescent lamp load (duo circuit): 400 VA
Max. fluorescent lamp load (parallel compensated): 400 VA
Fluorescent lamp load (parallel compensated): 360 VA
Max. switching current (cos phi: 0 VA)
Switching current (cos phi: 0.6): 12 A

Further details:
Installation relay for 35 mm rail, 1 NO contact and 1 NC contact for 20 A / 250 V AC, contact material AgSnO², max. switching capacities at 230 V AC: AC1 5000 VA, AC15 1000 VA, incandescent and halogen lamps 1000 W, fluorescent lamps with ECG 400 W, fluorescent lamps with CCG 360 W, energy saving lamps 200 W, LED (230 V AC) 200 W, LV halogen lamps or LED with ECG 200 W, LV halogen lamps or LED with CCG 400 W, coil data: 12 V DC, 1.25 W, 115 Ohm, width 17.5 mm, test button, relay protection class: IP 20, EAN: 8012823268132.
