Housing design: cylindrical
Thread size: M30 x 1.5
Output type: PNP make contact
Detection range: 10 mm
Connection type: M12 connector
Supply voltage: 10 to 30 Vdc
Length: 71 mm
DC voltage max: 30 V
Mounting type: flush mounting
Switching current: 200 mA
Housing material: nickel-plated brass
Operating temperature max: +75 °C

Standard series. RS Pro inductive sensors offer precise detection, long-term reliability, and high accuracy. The sensors are completely encapsulated and therefore offer high shock and vibration resistance. Properties and advantages include IP67 rating, nickel/brass housing with PBT sensing surface, flush mountable LED display, operating temperature range of -25 to +70 °C, and overload protection per EN60947-5-2.
