Houben superimposed igniter 140597
Manufacturer: Houben
Designation: Superimposed igniter
Wattage: 70-400W
Voltage: 220-240V
Frequency: 50Hz
Type: 140597
Electronic: Yes
Suitable for high pressure sodium lamp: Yes
Suitable for compact fluorescent lamp: No
Suitable for metal halide lamp: Yes
Suitable for low-pressure sodium lamp: No
Suitable for fluorescent lamp: No
Lamp wattage: 70-400 W

More details:
Electronic superimposed ignitors for high-pressure sodium lamps, halogen metal halide lamps, and ceramic arc tube lamps (70 - 400 W)
Nominal voltage: 220-240 V
Nominal frequency: 50-60 Hz
Phase position of ignition pulse: 60-90 °el and 240-270 °el
Ignition voltage: 4-5 kV
Max. lamp current: 5 A
Max. permissible housing temperature: 105 °C
Screw terminals: 0.75-4 qmm
Fixing: Threaded bolt with pre-mounted toothed lock washer and nuts
Weight: 130 g
Type: Z400MK
EAN: 4014364405971.
