Kaiser Wall/Ceiling Bend 1202-04

Manufacturer: Kaiser
Description: Wall/Ceiling Bend
Type: 1202-04
Outlet Design: Pipe
Mounting Type: Concrete
Self-Adhesive: No
With Dowels and Hook Screws: No
With Hook Screws: No
Number of Entries: 1
Outlet Length: 70 mm
Outlet Width: 30 mm
Outlet Diameter: 20 mm

The 30° wall and ceiling bend (1202-04) is designed to secure a continuously functioning conduit system at transition points. The particularly compact design of the end and transition fittings allows for the routing of conduits even between closely spaced reinforcement bars without the need for extensive modifications. The optimal radius of the wall and ceiling bends, along with the precise pipe fittings, prevent sharp edges at transitions and thus ensure the flexible pulling of cables from both directions.

Application Area: Cable and Pipe Routing Systems
Length: 70 mm
Width: 30 mm.
