Model: Main Clock

Peweta Swimming Pool Training Clock with LED Backlighting and Second Hand Cross: Intermediate time measurement during swim training. The Peweta Swimming Pool Training Clock features a corrosion-resistant, weatherproof aluminum housing in light gray (RAL 7035) with an IP 54 protection rating. For an additional fee, a custom paint finish is available. The clock can be used simultaneously by any number of swimmers. The 4-colored second hand cross indicates the elapsed time, with one full rotation corresponding to 60 seconds. Each swimmer waits until the next color of the second hand cross is at the 0 o'clock position (max. 14 seconds) and remembers the color of their "own" hand. Upon finishing (after 1 or 2 laps), the elapsed time in seconds can be read based on the position of the "own" second hand.

Dial (backlit):

• Material: Acrylic plastic
• Thickness: 5 mm
• White painted
• With red-black second markings and black numbers

Hands:

• 4-colored second hand cross
• Second hand advancement (jumping)

Front Glass:

• Shock-resistant, highly transparent Plexiglas XT plastic glass
• Thickness: 4 mm

LED Backlighting:

• Dial backlighting via durable, maintenance-free LEDs
• Operating voltage: 230 V AC/50–60 Hz

Main Clock, powered by 230 V AC, for wall mounting only. Recommended for continuous operation and/or when a fixed installation location is desired. For wall mounting and power supply via fixed connection only. Can be used for individual use as well as for time-synchronized parallel operation in combination with a secondary clock and control.

Secondary Clock, pulse-controlled 24 V, for wall mounting only. Recommended for time-synchronized parallel operation in combination with a main clock, powered by 230 V AC. Pulse-controlled 24 V for (fixed) connection to the central control. Control is required for operation.
