Technical featuresInsulation resistance measurement up to 3.1 GΩ with external voltage detection, test voltages: 50 V, 100 V, 250 V, 500 V, 1000 V according to EN 61557-2 / VDE 0413-2DAR: PI: 4-wire milliohm measurement with Kelvin connection and 200 mA or 1 A measuring current for precise measurement of smallest resistances with 1 microOhm resolution2-wire Rlow measurement with 200 mA test current according to EN 61557-4 / VDE 0413-4Wind fault measurement Multifunctional device True RMS measurement TRMSAC/AC+DC for current/voltage up to 10/100 kHzLow pass filter AC, AC+CDDirect current measurement Current measurement with clamp sensors: The transmission factor is adjustable with CLIP from 1:1 to 1:1000 and is taken into account in the ampere display.Capacitance measurementPrecision temperature measurement °C, °F for RTD and TC-K sensorsDiode measurement K flux up to 5.1 V) and continuity testAcoustic signalingCapture of min/max values, DATA HoldData logger thanks to integrated memory and real-time clock, also for single measured valuesPush/Print function transmits measured values to application software at the touch of a buttonProgrammable sequences for test routinesColor graphic displayModular power supply:Standard lithium quick-change battery, optional WPC module for inductive charging and power module with USB interface, change without interrupting the measuring circuit thanks to touch-protected module socketAutomatic socket lock (ABS) for the power inputTest probe with START (ISO) and STOREGehauses IP52, dust and drip-proof, replaceable rubber protective coverInterfaces: BT Bluetooth integrated - Device varicant with WLAN integrated - USB with optional power supply moduleWindows software IZYTRONIQ for documentation, creation of test reports and graphical evaluation of measurements.
