Stiebel Eltron Circulation Pump UP 25/7.5 PCV

Manufacturer: Stiebel Eltron
Designation: Circulation Pump
Type: UP 25/7.5 PCV
Delivery Head at Flow Rate (BEP): 8.4 kPa
Max. Delivery Head: 8.4 m
Double Pump: No
Rated Voltage: 230 V
Number of Phases: 1
Frequency: 50/60 Hz
Energy Efficiency Index (EEI): 0.2
Insulation Class according to IEC: F
Type of Speed Control: Stepless
Nominal Diameter, Outlet Connection: 1 1/2 inch (40)
Installation Length: 180 mm
Protection Class (IP): IPX4

The Stiebel Eltron Circulation Pump UP 25/7.5 PCV is an energy-efficient heating circulation pump with integrated electronic power control for transporting the heat transfer medium and stepless differential control.
