Wago Installation floor- 2203-7642 terminal,with handle,2,5 mm²,grey

Price in EUR including VAT
Ratings
Delivered between Mon, 21.7. and Wed, 23.7.
More than 10 pieces in stock at third-party supplier
Supplied by
Free shipping starting at 30,–

Product details

WAGO GmbH & Co. KG installation terminal block 2203-7642. Manufacturer: WAGO GmbH & Co. KG. Designation: Installation terminal block 2.5 mm² with handle. Type: 2203-7642. Connectable conductor cross-section fine-stranded without end sleeve: 0.25 to 4 mm². Connectable fine-stranded conductor cross-section with ferrule: 0.75 to 2.5 mm². Connectable solid conductor cross-section: 0.75 to 4 mm². Connectable stranded conductor cross-section: 0.25 to 2.5 mm². Rated current: 31 A. Rated voltage: 400 V. Electrical connection type 1: Spring-loaded connection. Electrical connection type 2: Spring-loaded connection. Number of potentials: 2. Mounting type: Top-hat rail TH35. Material of the insulating body: Thermoplastic. Operating temperature: 105 °C. Flammability class of the insulating material according to UL 94: V0. Width: 5.2 mm. Height: 95.6 mm. Depth: 46.6 mm. End plate required: Yes. Basic colour: Grey. With PE function: No. With N-disconnect slide: No. N-function possible: No. Installation floor terminal block with pusher 2.5 mm² L/L Push-in CAGE CLAMP® 2.50 mm² grey.

Key specifications

Item number
22724198

General information

Manufacturer
Wago
Category
Cable joints
Manufacturer no.
2203-7642
Release date
7.10.2022

Colour

Exact colour description
Grey
Colour
Grey

Material

Material
Thermoplastic resin
Material group
Plastic

Cable connection Properties

Cable connection type
Wire end ferrule
Suitable for cable cross-section
0.75 mm²

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Installation floor terminal 2.5 mm² with pusher, 2203-7642
Items per sales unit
50 x

Product dimensions

Length
46.60 mm
Width
5.20 mm
Height
95.60 mm

14-day cancellation right
30-day right of return
24 Months statutory warranty
