ABB Stotz S&J Relay TAL16-30-01 17-32VDC

Manufacturer: ABB Stotz S&J
Designation: Relay 17-32V DC
Type: TAL16-30-01 17-32VDC
Rated control supply voltage Us for DC: 17..32 V
Voltage type for actuation: DC
Rated operational current Ie for AC-1, 400 V: 30 A
Rated operational current Ie for AC-3, 400 V: 17 A
Rated operational power for AC-3, 400 V: 7.5 kW
Suitable for rail mounting: no
Number of auxiliary contacts as normally open: 1
Connection type main circuit: screw connection
Number of normally closed contacts as main contacts: 3

Further details:
The 3-pole TAL16 relays are primarily used for controlling three-phase motors and generally for controlling power circuits up to 690V AC or 220V DC. The relays can also be used for many other applications such as isolation, capacitor switching, and lighting. The single-tier, 3-pole relays of the TAL series are designed in a block construction.

• Main poles and auxiliary contact blocks: 3 main poles, 1 built-in auxiliary contact, installation of additional front or side-mounted auxiliary contact blocks is possible.
• Control circuit: DC operation with permanent magnet circuit and wide voltage range. The polarity at the coil terminals (A1+ and A2-) must be observed.

TAL relays have rail approval.
EAN: 3471522316516.
