Product details
Taichi represents the philosophical state of the undifferentiated Absolute and infinite potential. A motherboard that fulfills every task – with style. Be like water: formless, shapeless, versatile for any situation.
It is equipped with a composite VRM heatsink that combines a fan, a larger aluminum body, and a heat pipe for maximum heat dissipation. Compared to the conventional DIP-PCIe slot, the SMT-PCIe slot improves signal flow and maximizes stability at high speeds. This is a significant breakthrough to fully support the light speed of the PCIe 5.0 standard. The latest PCI Express 5.0 standard is capable of achieving an astonishing bandwidth of 128 GB/s to unleash the full potential of future high-end graphics cards.
Processor family | AMD 5000 Series |
Memory type | DDR5 RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | M.2 (4x), S-ATA (8x) |
Wireless transmission | Bluetooth, Wi-Fi |
Mainboard features | Front panel audio connector |
Item number | 22518301 |
Manufacturer | AsRock |
Category | Motherboards |
Manufacturer no. | 90-MXBJ00-A0UAYZ |
Release date | 14.9.2022 |
Form factor | E-ATX |
Socket | AM5 |
Chipset | AMD X670 |
Mainboard features | Front panel audio connector |
Operating system compatibility | Windows, Windows 10 |
BIOS type | UEFI AMI |
Wireless transmission | Bluetooth, Wi-Fi |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Processor family | AMD 5000 Series |
Memory form factor | DIMM |
Number of pins | 240 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 128 GB |
Max. RAM OC | 6600 MHz |
Supported memory speed | 6600 MHz |
Memory type | DDR5 RAM |
RAM buffer | Unbuffered |
Video connections | HDMI (1x) |
Video connection version | HDMI 2.1 |
Network connections | RJ45 (1x) |
Ethernet controller brand | Killer NIC |
Ethernet controller | Killer E3100G |
Max. port speed | 2.50 Gbit/s |
Chip | Realtek ALC4082 |
Audio channel | 5.1 channels |
Audio Connections | Jack 3.5mm (2x) |
Internal connection options | M.2 (4x), S-ATA (8x) |
Expansion slot | PCI Express x16 (2x) |
Exact USB ports | USB-A 3.2 Gen 1 (2x) |
Power connectors | 24-pin ATX |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 4 x Serial ATA cable |
Length | 267 mm |
Width | 305 mm |
Height | 267 mm |
Weight | 1600 g |
Length | 42.60 cm |
Width | 34.40 cm |
Height | 13.60 cm |
Weight | 3.79 kg |
