Delock SMA socket 90° PCB

Price in EUR including VAT
Ratings
BrandMore from Delock
Delivered between Mon, 16.3. and Fri, 20.3.
More than 10 pieces in stock at supplier
Free shipping starting at 30,–

Product details

SMA Socket 90° PCB Thread Length 5 mm

This socket from Delock is suitable for solder mounting on circuit boards. The gold plating prevents corrosion and ensures an optimal connection.
Connection: 1 x SMA Socket 90°
Pin: Gold-plated brass
Insulation: PTFE
Housing: Gold-plated brass
Frequency range: 0 - 6 GHz
Impedance: 50 Ohm
VSWR: 1.2
Thread type: 1/4" - 36 UNS - 2A
Thread length: 5 mm
Operating temperature: -55 °C to 165 °C
Voltage withstand: 500 V / 50 Hz
Solder mounting: 5 solder points
Dimensions (LxHxD): 15.3 x 14.0 x 6.0 mm
System requirements: Suitable board for mounting the SMA connector
Package contents: SMA Socket.

Key specifications

Cable + connector type
Various
Plug type
SMA

General information

Item number
14208682
Manufacturer
Delock
Category
Cables + Plugs
Manufacturer no.
65849
Release date
13.11.2020

Colour

Colour
Gold

Material

Material group
Metal
Material
Gold-plated brass

Cable + Connector Features

Cable + connector type
Various
Plug type
SMA
Compatible hardware
Various
Max. temperature
165 °C

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
77,88 kg
Climate contribution
EUR 0,45

Scope of delivery

Items per sales unit
1 pcs.
Scope of delivery
SMA socket

Product dimensions

Length
1.53 cm
Width
0.60 cm
Height
1.40 cm

Legal Notice

Product Safety

Package dimensions

Length
13 cm
Width
8 cm
Height
0.70 cm
Weight
236 g
