Eaton undervoltage release NZM1-XUHIV20L24DC

Manufacturer: Eaton
Designation: Undervoltage release for NZM1 with 2 separate VHI
Type: NZM1-XUHIV20L24DC
Rated control supply voltage Us at AC 50 Hz: 0 V
Rated control supply voltage Us at AC 60 Hz: 0 V
Rated control supply voltage Us at DC: 24 V
Type of voltage for actuation: AC
Type of electrical connection: Screw connection
Number of contacts as NO: 2
Delayed: No
Suitable for circuit-breakers: Yes
Suitable for motor-protective circuit-breakers: No
Suitable for overload relays: No

Eaton undervoltage release NZM1-XUHIV20L24DC: further details
Optional accessories for the NZM circuit-breaker series offer an extensive portfolio of application possibilities for worldwide use. Mounting is flexible and simple thanks to modular function groups.

Notes: For early closing of the undervoltage release in main switch applications as well as for interlocking and load shedding circuits. Can be used for emergency off devices in conjunction with emergency off pushbuttons. If the shunt release is live, contact with the main switch contacts is safely prevented during closing attempts. Advancing of the auxiliary contacts when switching on and off (manual operation): approximately 20 ms. Cannot be used in conjunction with remote operator NZM..-XR... Undervoltage release cannot be installed at the same time as leading auxiliary contact NZM..-XHIV.. or shunt opening release NZM..-XA...

Suitable for: NZM1(-4), N(S)1(-4)
EAN: 4015082596309.
