Range = TeSys D
Series = LC1D
Number of poles = 3
Coil voltage = 48 Vac
Nominal contact current = 80 A
Nominal contact voltage = 690 Vac
Contact configuration = 3 NO contacts
Number of auxiliary contacts = 2
Power = 22 kW
Connection type = Everlink
Length = 122mm
width = 55mm
Operating temperature max = +60°C

Everlink Tri-Polar Switch. TeSys switch with two Everlink power supply connections with hex screw. Allows a single unit assembly with an Everlink circuit breaker (vertical or side installation). For control of motors between 22 and 30 kW from AC3 category at 440 Vac. To control 60 to 80 A outputs for lighting and distribution.
