The Yageo M30 ultrasonic sensor is made of a 316L stainless steel housing and has a diameter of 30 mm. It is connected via an M12 connector and has a range of 1 m. The sensor's analog output is 4-20 mA. There is a blind zone of 155 mm, and the height of the sensor is 30 mm. The length of the sensor is 75.75 mm, and the ambient temperature is -25 °C. The sensor operates at a supply voltage of 12 volts and has a relative repeatability of 0.1. The adjustment process is categorized as other. The measurement range for length is 1 m, and the voltage type is DC. The sensor is synchronizable, and both the active area and the housing are made of other materials.

Features:

• Analog output type: 4 mA ... 20 mA
• Electrical connection type: M12 connector
• Blind zone: 155 mm
• Width of the sensor: 30 mm
• Height of the sensor: 30 mm
• Length of the sensor: 75.75 mm
• Diameter of the sensor: 30 mm
• Adjustment method: other
• Measurement range length: 1 m
• Ambient temperature: -25 °C
• Supply voltage: 12 V
• Relative repeatability: 0.1
• Voltage type: DC
• Synchronization possible: yes
• Material of the active area of the sensor: other
• Material of the housing: other.
