The Yageo XZ pre-wired socket, straight, M12, 4-pole, PVC 5m cable XZCPV1141L5 is an OsiSense connection solution featuring a 5-meter long polyvinyl chloride (PVC) cable. The 4-pole M12 socket is straight, and the cable sheath is black. Key specifications include a rated current of 3 A and a rated voltage of 250 V. The contact resistance is 5 Ohms. The contact base material and contact coating are made from other materials. The permissible cable outer temperature after installation without shock is -25 °C. This pre-wired socket is suitable for many industrial applications where a connection cable is needed due to the robust cable sheath and connectors. It is also a good choice for those requiring quick installation and reliable control. With the 4-pole M12 socket, high performance is achieved in a compact application.

Features:

• Number of poles: 4
• Electrical connection type, field side: M12
• Type of plug contact, field side: Female (socket)
• Cable entry arrangement, field side: straight
• Electrical connection type, housing side: other
• Type of plug contact, housing side: Female (socket)
• Cable entry arrangement, housing side: other
• Cable length: 5 m
• Material of cable sheath: Polyvinyl chloride (PVC)
• Halogen-free: no
• Color of cable sheath: black
• With LED indicator: no
• Shielded: no
• Type of conductor: multi-core
• Cross-linked: no
• Material of contact base: other
• Material of contact coating: other
• Permissible cable outer temperature after installation without shock: -25 °C
• Rated current: 3 A
• Rated voltage: 250 V
• Contact resistance: 5 Ohms
• Protection class (IP): other
• Permissible cable outer temperature during installation/handling: -.
