Schneider Electric Rain Protection Roof NSYTJ8040

Manufacturer: Schneider Electric
Description: Rain Protection Roof
Dimensions: 800 x 400 mm
Type: NSYTJ8040
Suitable for roof covering: Yes
Suitable for floor covering: No
Width: 809 mm
Height: 42 mm
Depth: 400 mm
Suitable for installation width of the enclosure: 800 mm
Suitable for installation depth of the enclosure: 400 mm
Material: Steel
Surface treatment: Powder-coated
Color: Gray (RAL 7035)
With ventilation: No
Suitable for outdoor installation: Yes
With cable entry: No

The NSYTJ8040 rain protection roof from Schneider Electric is designed for wall-mounted enclosures. It has a width of 800 mm and a depth of 400 mm. This accessory is a universal wall-mounted roof that is installed on the enclosure and secured with four M6 screws. It is made of galvanized steel with an epoxy-polyester powder coating in gray (RAL 7035) for Spacial CRN/S3D. The package includes the user manual, mounting elements, and the roof.
