Siemens digital industrial overload relay 3RU2116-0FC0

Manufacturer: Siemens Digital Industries
Designation: Overload relay 0.35-0.50A
Type: 3RU2116-0FC0
Adjustable current range: 0.35 to 0.5 A
Max. operating voltage: 690 V
Mounting type: Direct mounting
Connection type main circuit: Spring-loaded connection
Rated operational voltage: 690 V
Number of auxiliary contacts as NC contacts: 1
Number of auxiliary contacts as NO contacts: 1
Tripping class: Class 10
Reset function input: No
Reset function automatic: Yes
Reset function push-button: Yes

Further details:
This overload relay provides thermal protection for motors with a current range of 0.35 to 0.50 A, designed for size S00 and Class 10 contactor mounting. The main circuit features spring-loaded terminals, and the auxiliary circuit also utilizes spring-loaded terminals. It includes manual and automatic reset options. The SIRIUS 3RU2 thermal overload relay offers current-dependent protection against excessive heating due to overload or phase failure. This series is flexible and cost-effective, with worldwide approvals and applications in potentially explosive atmospheres. Available with various setting ranges for the overload release, it supports screw or spring-cage connections for quick, maintenance-free, and vibration-proof installation. The accessories are compatible with sizes S00 to S3. The SIRIUS modular system is simple, efficient, and always up-to-date.
EAN: 4011209781979.
