Siemens Digital Industrial Relay LZS:RT4B4L24

Manufacturer: Siemens
Designation: Relay 24VDC 2W Red LED
Type: LZS:RT4B4L24
Electrical connection type: Screw connection
With removable terminals: no
Rated control supply voltage Us at DC: 24 V
Type of voltage for actuation: DC
Drive, polarity: polarized
Switching behavior of the drive: monostable
Number of contacts as changeover: 2
With forced-guided contacts: no
Type of switching contact: Single contact
Complete device with base: yes
With LED indicator: yes
Protection class (IP): IP20
Width: 15.5 mm
Height: 77 mm
Depth: 71 mm

Further details:
Complete relay device 2 W, DC 24 V red LED module, base with logical separation, screw connection. Coupling relay with SIRIUS LZS relay for galvanic isolation, contact multiplication, for switching small loads and as potential switching. The coupling relays feature tool-free wiring and vibration-proof connection thanks to push-in spring terminals. Bases with logical separation allow for straightforward wiring. The switching capacity is tested according to AC-15 and DC-13. Thanks to hard gold-plated contacts, cooperation with electronic controls is optimal.

Devices are available as complete devices or individual modules in the designs RT, PT, and MT, with or without logical separation, in various coil voltages, and in screw connection or with plug terminals (Push-In). A wide range of accessories such as plug bases, holding/ejecting brackets, wiring brackets, and LED modules are available. SIRIUS relays - a program for all cases.
