Telemechanique Sensors Inductive Proximity Switch XS7C4A1MPP20

Manufacturer: Telemechanique Sensors
Description: Inductive proximity switch 24-240V AC/DC
Type: XS7C4A1MPP20
Width of the sensor: 40 mm
Height of the sensor: 40 mm
Length of the sensor: 117 mm
Mechanical installation condition for sensor: flush
Switching distance: 15 mm
Suitable for safety functions: no
Type of switching function: programmable/configurable
Type of switching output: 2-wire
Type of electrical connection: screw connection
Number of semiconductor outputs with signaling function: 1
Type of actuation: metallic target
Type of interface: none
Type of interface for safety-related communication: none
Housing design: rectangular
Housing coating: other
Cascadable: no
SIL according to IEC 61508: none
Performance Level according to EN ISO 13849-1: none
Max. output current at safe output: 200 mA
Supply voltage: 24..240 V
Rated control supply voltage Us at AC 50 Hz: 24..240 V
Rated control supply voltage Us at AC 60 Hz: 24..240 V
Rated control supply voltage Us at DC: 24..240 V
Voltage type: AC/DC
Switching frequency: 50 Hz
With monitoring function for downstream devices: no
Material of the housing: plastic
Pressure resistant: no
Explosion protection category for gas: none
Explosion protection category for dust: none
Interference immunity against magnetic fields: immune to magnetic DC and AC fields

Telemechanique Sensors Inductive Proximity Switch XS7C4A1MPP20: additional details
XS7 Inductive proximity switch 40x40x117mm, PBT plastic housing, switching distance Sn 15mm, power supply 24-240 VAC/DC, terminals.
