Technical data
Switching position: 2-1: ON 2-3: (ON)
2-1: ON
2-3: (ON)
Contacts: 1A with load resistance at 120Vac or 38Vdc
electrical life: 60000 switching cycles at full load
Contact resistance: initially max. 20mohm at 2-4Vdc 100mA for silver and gold plated contacts
initially max. 20mohm at 2-4Vdc
100mA for silver and gold plated contacts
Insulation resistance: 1000Mohm min.
Dielectric strength: 1000Vrms at sea level
Operating temperature: -30°C to +85°C
Materials: Housing: Diallyl phthalate (DAP) Plunger: Thermoplastic, polyester Thread: Nickel-plated brass Housing: Stainless steel Support for terminals: Tinned brass, electrolytic Contacts: Silver-plated Terminals: Silver-plated
Housing: Diallylphthalate (DAP)
Plunger: thermoplastic, polyester
thread: nickel-plated brass
Housing: stainless steel
support for connections: tinned brass, electrolytic
contacts: silver plated
connections: silver plated
