The SCDV 3.81 from Weidmüller is a highly advanced PCB connector designed for use in demanding electronic applications. With a pin count of 4 and a pitch of 3.81 mm, this connector provides a reliable connection for various electronic components. The side-sealed design and solder connection facilitate easy integration into printed circuit boards, while the 90° exit direction ensures space-saving installation. The double pin header is specifically designed for wave soldering processes and allows for the use of two interfaces on the same footprint, increasing efficiency during assembly. Additionally, the SCDV 3.81 offers space for labeling and coding, making identification and organization in complex circuits easier.

• Double pin header for efficient wave soldering process
• 90° exit direction for space-saving installation
• Two staggered levels for easy access to connections
• Space for custom labeling and coding
• Compatible with common connectors in a 3.81 mm pitch.
