Best selling Bike frames
Here's a ranking of the best products in this category. To give you a quick overview, we've also added some key information about the products.
1. Surly Ogre MTB Frame Kit, 27.5+/29", purple
The Ogre is designed as the ultimate steel utility vehicle. It is perfect for commuting, especially for those long rides home where you might stop for a few drinks along the way. Whether it's snow, sleet, or humid air, this bike is an ideal commuter vehicle year-round. You can carry so much luggage that you might not even need to go home if you don’t want to.
The frame features Gnot Boost 145 mm dropouts, allowing it to accommodate rear wheels in 12 x 142 mm or Boost 12 x 148 mm configurations. Special adapters are required for use with quick releases, which are not included.
There are mounts for racks both front and rear, as well as mounts for fenders front and rear.
Frame: 4130 Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, ED coated.
Fork: 4130 Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated.
Seatpost clamp: Surly Stainless Ø30 mm.
Headset: Cane Creek EC34 max.
Seatpost diameter: 27.2 mm.
Front hub spacing: 10 x 100 mm.
Rear hub spacing: 12 x 142 mm, 12 x 148 mm (Gnot Boost dropouts).
Brake mount: IS 2000.
Derailleur mount: High Direct Mount Top Pull (Ø31.8 mm).
Bottom bracket: BSA 73 mm.
Max tire width: 27.5 x 3.0" / 29 x 2.6" (without fenders).
Max rotor size: 203 mm front / 160 mm rear.
Max chainring size: 42 teeth single, 46/34 teeth double, 48/36/24 teeth triple, 46 teeth single Boost, 48/42 teeth double Boost.
2. Surly Karate Monkey
Multipurpose Hardtail Mountain Bike
The Surly Karate Monkey delivers a robust, lively ride on all types of rough terrain. Its frame is an incredibly versatile canvas for any dirty masterpiece your mind can conjure. According to the calculator (Thor), it can be built in about 487 different configurations. Originally designed as a 29er (and the frame that sparked the 29-inch wheel movement), the latest Karate Monkey is engineered to perform just as admirably as a 27.5+.
Details:
- Compatible with Stealth dropper posts
- 2 bottle cage mounts
- Front axle size: 15 x 110 mm
- Max rotor size: 203 mm
- Headset size: ZS44/28.6 // EC44/30
- Max tire clearance: 27.5 x 3.0 / 29 x 2.5
- Max chainring size: 1x (Mtn): 28T / 2x (Mtn): 24/34T / 1x (Boost): 32T / 2x (Boost): 24/36T
- Seat tube outer diameter: Ø 33.1 mm
- Max front travel: 140 mm (27.5+)
- Derailleur: High direct mount top-pull (Ø34.9mm)
Frame:
- Material type: Steel
- Additional features: 4130 Chromoly, Natch tubing, double-butted main triangle, trumpet flared tubes, TIG welded, ED coated
- Intended use: MTB
- Type: Frame with rigid fork
Measurements:
- Rear hub spacing: 142 mm
- Compatible axle diameter: 12 mm
- Head tube size (inches): 1 1/8 inch
- Bottom bracket shell: 73 mm
- Seat post size: 30.9 mm
Included:
- Package includes: 1 Surly Karate Monkey frame kit 27.5+ / 29" including Surly axles
Design:
- Bottom bracket standard: BSA
Features:
- Features: Disc brake mounts.
3. Surly Disc Trucker touring bike frame kit, 26", 42cm, pea lime soup
Bike frames
−10%
Returned & Tested
EUR574,44 currently EUR639,– new
Surly Disc Trucker touring bike frame kit, 26", 42cm, pea lime soup
4. ATC Maxle HR
The Maxle HR from ATC is a high-quality thru-axle specifically designed for bike frames. With a size of 142/12mm and a length of 174mm, this quick release solution offers a reliable and user-friendly way to securely attach the wheel to the frame. The construction ensures a stable connection suitable for both off-road and on-road use. Its ease of use allows for quick and uncomplicated wheel changes, which is particularly beneficial for cyclists who frequently switch between different riding environments. The Maxle HR is an essential accessory for anyone who values safety and efficiency. Its robust design ensures that the thru-axle functions reliably even under demanding conditions. With the Maxle HR, cyclists can be confident that their wheel is optimally secured, contributing to improved handling and increased safety.
5. Salsa Alternator dropout Swing plate thru axle left mudguard eyelets
Bike frames
only 1 piece
EUR22,91 was EUR24,90
Salsa Alternator dropout Swing plate thru axle left mudguard eyelets
6. Surly Grappler MTB Frame Kit, 27.5", purple
7. Surly Ogre MTB Frame Kit, 27.5+/29", purple
The Ogre is designed as the ultimate steel utility vehicle. It is perfect for commuting trips where you take the long way home and find a few drinks along the way. Whether it's snow, sleet, or humid air, this bike is an ideal commuter vehicle all year round. You can carry so much luggage that you don’t even have to go home if you don’t want to.
The frame features Gnot Boost 145 mm dropouts, allowing it to be used with rear wheels in 12 x 142 mm or Boost 12 x 148 mm. Special adapters are required for use with quick releases, which are not included.
Mounts for front and rear racks as well as for front and rear fenders are available.
Frame: 4130 Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, ED coated.
Fork: 4130 Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated.
Seatpost clamp: Surly Stainless Ø30 mm.
Headset: Cane Creek EC34 max.
Seatpost diameter: 27.2 mm.
Front hub spacing: 10 x 100 mm.
Rear hub spacing: 12 x 142 mm, 12 x 148 mm (Gnot Boost dropouts).
Brake mount: IS 2000.
Front derailleur mount: High Direct Mount Top Pull (Ø31.8 mm).
Bottom bracket: BSA 73 mm.
Max tire width: 27.5 x 3.0" / 29 x 2.6" (without fenders).
Max rotor size: 203 mm front / 160 mm rear.
Max chainring size: 42 teeth single, 46/34 teeth double, 48/36/24 teeth triple, 46 teeth single Boost, 48/42 teeth double Boost.
8. Salsa Fargo frame kit, 29", L
9. Surly Preamble Frame Kit, 700C, best buds green
10. Fahrer Standard
The Standard Velor frame from Fahrer is a practical solution for e-bike owners who want to optimally protect their battery contacts. This frame is specifically designed for e-bike applications and provides effective coverage for the connection contacts on the frame when the battery is removed. Made from high-quality neoprene, the frame protects against weather influences, frost, dirt, and mechanical damage. With compact dimensions, the frame is easy to handle and integrates seamlessly into the design of the e-bike. The Standard Velor frame is an ideal choice for anyone who values durability and functionality.
- Protection against weather influences and mechanical damage
- Made from durable neoprene
- Specifically designed for e-bike applications.
