Assa Abloy ML53PA PIN is an autonomous, battery-operated cabinet lock. The lock is designed for use in dry rooms but can also be used in damp areas when combined with a rubber seal. An additional hole for the upper screw can be retrofitted through the pre-drilled holes. For an enhanced user experience, the lock features acoustic and visual indicators. It can be powered via USB when the batteries are completely drained. The handle includes a torque overload coupling function.

Technical specifications:

• Number of unlock cycles before battery replacement: 25,000
• Batteries: 3 x AAA (included)
• Max. 10 user codes
• USB connection: Micro Type B for external power supply
• Without lever/locking bolts (see accessories for other levers/locking bolts upon request)

The lock has three card levels:

• User code (4 digits)
• Caretaker/employee code (6 digits)
• Master code (8 digits)

Function:
The lock can operate in two different modes:

• Private mode: the lock is unlocked with the same pre-programmed codes.
• Public mode: the lock can be locked with any one-time code. After unlocking, a new user code can be entered.

With quick setup, multiple cards can easily be used in either of the two modes mentioned above. Additional functions can be programmed in or out using standard programming. The lock can be set to unlock based on time, meaning it will automatically unlock after a preset period. After repeated incorrect code entries, the timeout function is activated.

Installation variant: vertical
Direction: universal
Dimensions (mm): 152 x 34/36 x 20.5/28
Door thickness (mm): 16-22
Type: ML53PA PIN
Material: Plastic silver/black
Design: PIN - vertical long form
Brand: Assa Abloy
Contents (ST): 1.
