Dehn SOEHNE Combination arrestor valve TT 255

Price in EUR including VAT
Delivered between Tue, 9.9. and Thu, 11.9.
7 pieces in stock at supplier
free shipping

Product details

Multipole DEHNventil modular combination arrester, type 1 + type 2 according to EN 61643-11 on spark gap basis, consisting of base part and plug-in protection modules. Highest system availability due to RADAX flow follow current limitation. Enables end device protection. For protecting low-voltage consumer equipment against surges, even in the event of direct lightning strikes. Can be used according to the lightning protection zone concept at interfaces 0A-2.

Key specifications

Surge protection type
Combination arrester
Number of conductors
4 x
Test class
Type 1
Mounting type
Top-hat rail
Item number
13051174

General information

Manufacturer
Dehn
Category
Surge protection
Manufacturer no.
951315
Release date
7.4.2020
External links

Surge protection properties

Surge protection type
Combination arrester
Number of conductors
4 x
Lightning impulse current
100 kA
Rated leakage surge current
0.05 kA
Nominal voltage
230 V
Protection level
1.50 V
Mounting type
Top-hat rail
Test class
Type 1
Protection type (IP code)
IP20

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
17 m
Width
12 m
Height
12 m
