Eaton fireman's switch SOL30-SAFETY/2MC4-U

Manufacturer: Eaton
Designation: Fireman's switch
Rated current: 30A
Rated voltage: 230V
Frequency: 50Hz
Type: SOL30-SAFETY/2MC4-U

Version as main switch: No
Version as maintenance/repair switch: Yes
Version as safety switch: No
Version as emergency stop device: No
Version as reversing switch: No

Number of switches: 1
Max. rated operational voltage Ue at AC: 1000 V
Rated operational voltage Ue at AC: 1000 V
Rated continuous current Iu: 32 A
Rated continuous current at AC-23, 400 V: 0 A
Rated continuous current at AC-21, 400 V: 0 A
Rated operational power at AC-3, 400 V: 0 kW
Rated short-time withstand current Icw: 0.36 kA
Rated operational power at AC-23, 400 V: 0 kW
Switching capacity at 400 V: 30 kW
Conditional rated short-circuit current Iq: 0 kA
Number of poles: 2
Number of auxiliary contacts as change-over contacts: 1

Motor drive optional: No
Motor drive integrated: No
Voltage release optional: Yes

Unit design:
Suitable for floor mounting: Yes
Suitable for front mounting 4-hole: No
Suitable for front mounting central: No
Suitable for distributor installation: No
Suitable for intermediate installation: No

Colour of the actuating element: Black
Actuating element version: Toggle
Lockable: No
Connection type main circuit: Other
Protection class (IP), front side: IP65
Protection class (NEMA): Other

Further details: Fireman's switch, protection class: IP65, standards and regulations: IEC/EN 60 947-3, EAN: 4015081406326.
