Hager MBN516. Number of poles: 2P. AC input frequency: 50/60 Hz, Nominal current output: 16 A.

Price in EUR including VAT, plus shipping
Ratings
Delivered between Wed, 25.6. and Fri, 27.6.
More than 10 items in stock at supplier

Product details

Hager Circuit Breaker MBN516

Manufacturer: Hager
Description: Circuit breaker 1p+N, B-16A, 6kA
Type: MBN516
Installation depth: 70 mm
Tripping characteristic: B
Number of poles (total): 2
Number of protected poles: 1
Rated current: 16 A
Rated voltage: 230 V
Rated insulation voltage Ui: 500 V
Rated impulse voltage withstand Uimp: 4 kV
Rated breaking capacity Icn according to EN 60898 at 230 V: 6 kA
Type of voltage: AC
Rated breaking capacity Icu according to IEC 60947-2 at 230 V: 6 kA
Frequency: 50..60 Hz
Power loss: 4.2 W
Energy limitation class: 3
Flush-mounted: yes
Switching neutral conductor: yes
Overvoltage category: 3
Pollution degree: 2
Additional devices possible: yes
Width in module units: 2
Protection class (IP): IP20
Ambient temperature during operation: -25..70 °C
Connectable conductor cross-section multi-stranded: 1..25 mm²
Connectable conductor cross-section single-stranded: 1..35 mm²
Explosion-proof: no

Hager Circuit Breaker MBN516: further details
Circuit breaker 1P+N 6kA B-characteristic 16A 2 modules. Circuit breaker according to DIN EN 60898-1 (VDE 0641-11) with delayed thermal tripping for overload protection and electromagnetic tripping for short-circuit protection. Suitable for retrofitting additional devices. Labeling option directly on the device and individual removal from the phase rail connection by unlocking the DIN rail quick fastening.

Key specifications

Circuit breaker type
Miniature circuit breaker
Length
70 mm
Width
2 mm
mounting style
Flush-mounted
number of poles
2
Item number
20020799

General information

Manufacturer
Hager
Category
Residual-current device
Manufacturer no.
MBN516
Release date
16.3.2022
Sales rank in Category Residual-current device
12 of 9300

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
mounting style
Flush-mounted
number of poles
2
Tripping characteristic
B
Rated current
16 A
Rated voltage
230 V
voltage type
AC
Rated insulation voltage Ui
500 V
Protection type (IP code)
IP20

Origin

Country of origin
France

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
Width
2 mm

Package dimensions

Length
8 cm
Width
7 cm
Height
4 cm
Weight
170 g
