Lift Advanced HF Folding Hinge

• For wooden fronts or frame fronts made of wood or 19 mm wide aluminum profiles
• Adjustable opening force
• Integrated Silent System - dampened closing motion
• Flap weight including handle 3.8 – 15.4 kg
• Unequal flap distribution possible from 490 mm clear body height
• Three-dimensional front adjustment: height ± 2 mm, side ± 2 mm, tilt/depth ± 2 mm
• No need for a crossbar or center hinge
• Powder-coated aluminum in silver / plastic in gray
• The use of quick-mount cup hinges with an opening angle of at least 110° is recommended, e.g., Sensys 8645i or Intermat 9943, please order separately
• Gas pressure springs to be ordered separately

Set includes:

• 1 set of flap hinges, right and left
• 1 set of cover caps, right and left
• Mounting material.
