MDT technologies Switch actuator 4-fold 2TE AKK-0416.03 Manufacturer: MDT technologies Designation: Switch actuator 4-fold 2TE REG,16A,230VAC,Komp. Type: AKK-0416.03 Bus system KNX: yes Bus system KNX radio: no Bus system radio bus: no Bus system LON: no Bus system Powernet: no Other bus systems: without Radio bidirectional: no Mounting type: REG Width in division units: 2 On-site/manual operation: yes With LED display: yes Max. Max. switching capacity: 2000 W Suitable for C-load: no Max. number of switching outputs: 4 Max. number of switching outputs: 4 Max. switching current: 16 A Rated current: 16 A Rated operating voltage: 230 V Different phases connectable: no With bus coupling: yes Bus module removable: no Modular expansion option: no Protection class (IP): IP20MDT technologies Switch actuator 4-fold 2TE AKK-0416.03: Further detailsSwitch actuator 4-fold, 2TE, REG, 16A, 230VAC, compact, 70MikroF, 10EVG. Compact version with bistable relay current max. 16A with resistive load, 70MikroF/10EVG. Function extension. Pushbutton for manual operation and LED indication for each channel. Normally open and normally closed operation. Status indication for manual operation. Time functions (on/off delay). Extensive staircase lighting and pulse functions. Feedback function (also for manual operation) for all channels. Logical links. Extended scene functions per channel. Central functions and blocking objects for forced operation. Adjustable behavior on bus voltage failure/restoration. Common L-connection. Supply voltage via KNX bus. Fast application download (long frame support for ETS5). , EAN: 4251916130244.
