Pollmann Main line branch terminal
Price in EUR including VAT
Free shipping starting at 30,–
1 blue main line branch terminals 14 M2 modular stackable mounting on 35 mm mounting rail according to EN 60715 color coding in accordance with valid wire colors Ui 1000 VDE certified terminal block tinned. Suitable for aluminum conductors. The compact size results in less space required in the distribution. Now, 3525 mm2 outputs can be realized, where conventionally only 2516 mm2 were possible. The modular stackability leads to an unprecedented variability. Depending on the needs, the color-coded terminals can be combined and released again with a tool. PV suitability: cable entries with insulating collars allow the use of the terminal up to 1000 rated voltage according to VDE 0613 EN 60998. The terminals are also fully finger-safe without a connected conductor. For use with fine-stranded conductors, the terminal depth is adapted to the usual lengths of ferrules HLAK 35? 25 mm, HLAK 25? 16 mm. The new terminals are VDE approved according to VDE 0603-2 for meter locations and distributions. HLAK 25-16 M2 blue.
Item number | 34356962 |
Manufacturer | Pollmann |
Category | Cable joints |
Manufacturer no. | 2080174 |
Release date | 17.5.2023 |
Exact colour description | Blue |
Colour | Blue |
Material | Tinned terminal block |
Material group | Metal |
Cable connection type | Jointing clamp |
Suitable for cable cross-section | 25 mm² |
Plug type | Flat |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Main line branch terminal |
Items per sales unit | 1 x |
Length | 45 mm |
Width | 36 mm |
Height | 40 mm |
Length | 16.20 cm |
Width | 10.30 cm |
Height | 4.30 cm |
Weight | 90 g |
