Pipe connection A = Push-in installation 6 mm
Pipe connection B = Push-in installation 6 mm
Branch pipe connector = Push-in installation 6 mm
Housing material = Polyoxymethylene
Surface = Nickel-plated
Maximum operating pressure = 10 bar
Maximum operating temperature = +60 °C
Pipe connection B - Type = Push
Pipe connection A - Pipe size = 6 mm
Pipe connection B - Pipe size = 6 mm
Branch pipe connector - Pipe size = 6 mm
Minimum operating temperature = 0 °C
Branch pipe connector - Type = Push
Pipe connection A - Type = Push

RS Pro One-Touch Fittings – metric system. Features and benefits: One-touch push connection for immediate hose attachment. All models are useful for line installation in tight spaces due to the hexagonal wrench. Instant disconnection of the robust sleeve made from technical plastic (POM) by pressing the sleeve and easily removing the pipe from the fitting. Fittings are treated with Teflon or have an O-ring on the thread. Nickel-plated brass housing provides protection against contamination for extended durability. Technical specifications: Suitable for use with air. Operating pressure range: 0-150 psi. Negative pressure: –29.5 in Hg. Operating temperature range: 32 °F to 140 °F. Product application information: Usable in pneumatic pipelines and a variety of applications.
