Inner diameter = 20 → 23mm
Clamp type = O-Clip
Material = Steel
Inner diameter min = 20mm
Inner diameter max. = 23mm
Band width = 9mm

Requires closing pliers for installation and removal. Both closing and side closing pliers or alternatively cable cutters can be used. To fully install an ear, the first ear is closed so that the first ear can be easily opened. This provides high stability so that the clamp resists shrinkage, pressure, and vibration due to wear and temperature changes. Use side-closing pliers when access to the ear is limited. A selection of stainless steel O-clips and a 200-piece galvanized steel assortment are also available. O-Clips. The RS Pro series of double-ear O-Clips is available in a range of sizes from 5 mm minimum diameter to 27 mm maximum diameter and a bandwidth from 6 mm to 10 mm. Features and Benefits. Can be used on small tubing where a screw clip mechanism is lacking. 1-piece construction provides positive clamping action Rounded band edges prevent damage to tubing Tamper-proof for added security. Typical Applications:. Commonly used for maintenance and OEM applications Suitable for applications involving rubber or plastic air, liquid, gas and steam hoses, as well as coaxial and other electrical cables Used in a variety of industries including mining, construction, heating and ventilation, welding, medical, military and aircraft Also suitable for low pressure hydraulic applications.
