Siemens 5SV3624-4 2-pole type B 40A 300mA 230V RCD circuit breaker

Price in EUR including VAT, free shipping
Ratings
BrandMore from Siemens
Delivered between Tue, 1.7. and Thu, 10.7.
Supplied by

Product details

Siemens Dig.Industr. RCD 5SV3624-4

Manufacturer: Siemens Dig.Industr.
Description: Type B RCD, 300 mA, 40 A
Type: 5SV3624-4
Number of Poles: 2
Rated Voltage: 230 V
Rated Current: 40 A
Rated Residual Current: 0.3 A
Mounting Type: DIN Rail
Residual Current Type: B
Selective Type: No
Short-Time Delayed Type: Yes
Short-Circuit Strength (Icw): 10 kA
Surge Current Strength: 3 kA
Voltage Type: AC
With Locking Mechanism: Yes
Frequency: 50 Hz
Additional Devices Possible: Yes
Protection Class (IP): IP20
Width in Division Units: 4
Installation Depth: 70 mm
Ambient Temperature During Operation: -25 to 45 °C
Connectable Conductor Cross-Section Multi-Wire: 0.75 to 35 mm²
Connectable Conductor Cross-Section Single-Wire: 0.75 to 35 mm²
Explosion-Proof: No

Siemens Dig.Industr. RCD 5SV3624-4: Additional Details
RCD, 2-pole, Type B, short-time delayed, In: 40 A, 300 mA, Un AC: 230 V.
The SENTRON 5SV3 RCDs provide comprehensive protection for people and property against electric shock. These RCDs offer reliable safety during installation due to the standard included gripping and touch protection. With the convenient slider manual operation, you can easily detach the RCDs from the DIN rail or busbar system without tools. The data matrix code on the device provides quick access to all technical data in the Siemens Industry Online Support App. The SENTRON protective devices can be expanded with a wide range of functions using the comprehensive accessories from the modular system. Optimal technology for your safety - exclusively from Siemens.
EAN: 4001869548920.

Key specifications

Circuit breaker type
Fault current circuit breaker
Length
70 mm
mounting style
Top-hat rail
number of poles
2
Item number
31989501

General information

Manufacturer
Siemens
Category
Residual-current device
Manufacturer no.
5SV36244
Release date
24.10.2022

Circuit Breaker Features

Circuit breaker type
Fault current circuit breaker
mounting style
Top-hat rail
number of poles
2
Tripping characteristic
B
Rated current
40 A
Rated current
0.3 A
Rated voltage
230 V
voltage type
AC
Residual current (rated differential current)
0.30 A
Protection type (IP code)
IP20

Origin

Country of origin
Germany

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Siemens fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
