Siemens Dig.Industr. Circuit Breaker 5SL6513-7

Manufacturer: Siemens Dig.Industr.
Designation: Circuit breaker 230V 6kA 1+N C 13A
Type: 5SL6513-7
Installation depth: 70 mm
Tripping characteristic: C
Total number of poles: 2
Number of protected poles: 1
Rated current: 13 A
Rated voltage: 230 V
Rated breaking capacity Icn according to EN 60898 at 230 V: 6 kA
Voltage type: AC
Rated breaking capacity Icn according to EN 60898 at 400 V: 6 kA
Rated breaking capacity Icu according to IEC 60947-2 at 230 V: 6 kA
Rated breaking capacity Icu according to IEC 60947-2 at 400 V: 6 kA
Frequency: 50 Hz
Energy limiting class: 3
Flush-mounted: no
Switching neutral conductor: yes
Overvoltage category: 3
Pollution degree: 2
Additional devices possible: yes
Width in division units: 2
Protection class (IP): IP20
Ambient temperature during operation: -25..45 °C
Connectable conductor cross-section multi-stranded: 0.75..25 mm²
Connectable conductor cross-section single-stranded: 0.75..25 mm²
Explosion-proof: no

Siemens Dig.Industr. Circuit Breaker 5SL6513-7: additional details
Circuit breaker 230V 6kA, 1+N-pole, C, 13A
SENTRON 5SL circuit breakers provide safe short-circuit and overload protection for standard applications in residential and commercial buildings. Tool-free installation and removal of the device. Simple wiring of the supply through the rear busbar. The 5SL circuit breakers are available in 1-, 2-, 3-, 4-, as well as 1+N and 3+N pole versions, along with other special types. The extensive accessories, such as auxiliary switches, allow for versatile function expansion. Simply safe with SENTRON protection devices.
