Simonswerk Object tapes TECTUS TE 640 3D FR
More than 10 pieces in stock at supplier
Product details
The TECTUS TE 640 3D FR hinge from Simonswerk is specifically designed for use on fire doors. It offers an innovative solution for flush doors that are mounted on wooden or steel frames. The hinges are completely concealed, allowing for an aesthetic and functional integration into the door. Thanks to the maintenance-free sliding bearing technology, they ensure smooth operation over a long period. With an opening angle of up to 180°, they provide maximum flexibility in daily use. The 3D adjustability allows for precise adjustments in three dimensions, significantly simplifying installation and operation. These features make the TECTUS TE 640 3D FR an ideal choice for object and functional doors that require both safety and user-friendliness.
- Completely concealed for aesthetic integration
- Maintenance-free sliding bearing technology for long-term reliability
- Opening angle up to 180° for maximum flexibility
- 3D adjustable in height, side, and pressure
- Suitable for leaf weights of up to 200 kg.
Door hinge | Left |
Material | Steel |
Material group | Metal |
Door hinge type | Object tape |
Opening angle | 180° |
Item number | 10879120 |
Manufacturer | Simonswerk |
Category | Door hinge |
Manufacturer no. | 5 400629 0 12402 |
Release date | 28.3.2019 |
Sales rank in Category Door hinge | 2 of 1357 |
Colour | Silver |
Exact colour description | silvery |
Material group | Metal |
Material | Steel |
surface finish | Coated |
Door hinge type | Object tape |
Scope of application | Door |
Door hinge | Left |
Opening angle | 180° |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 240 mm |
Width | 240 mm |
Height | 240 mm |
Product Safety |
