Striebel&John NH switch-disconnector ZH414 Manufacturer :Striebel&John Designation :NH switch-disconnector 160A Type :ZH414 Design as main switch :yes Design as safety switch :no Max. Rated operational voltage Ue at AC :400 V Rated continuous current Iu :160 A Conditional rated short-circuit current Iq :50 kA Rated short-time withstand current Icw :50 kA Suitable for fuse links :NH00 Number of poles :3 With fuse monitoring :no Connection type main circuit :clamping bracket Cable entry :other Equipped with connectors :no Suitable for floor mounting :no Suitable for front mounting :no Suitable for busbar mounting :yes Version of actuating element :cover handle Position of actuating element :front Motor drive optional :no Motor drive integrated :no Version as EMERGENCY STOP device :no Protection class (IP), front side :IP30 Striebel&John NH switch-disconnector ZH414: further details Fuse switch-disconnector NH00, rated current (In) max. 160 A, without disconnector panels, with U-clamps up to 50 mm², for mounting with EDF mounting frame on busbar systems, Cu 12 x 5 mm or Cu 12 x 10 mm, busbar spacing 40 mm. , EAN: 4011617629504.
