−15%

ABB Kleinschütz

Price in EUR including VAT
was EUR60,64
Ratings
Delivered between Mon, 27.7. and Sat, 8.8.
free shipping

input voltage3

Number of poles2

Product details

ABB Stotz S&J miniature contactor B7D-30-01-01

Manufacturer: ABB Stotz S&J
Designation: Miniature contactor with diode
Type: B7D-30-01-01
Rated control supply voltage Us at DC: 24 V
Voltage type for actuation: DC
Rated operational current Ie at AC-1, 400 V: 20 A
Rated operational current Ie at AC-3, 400 V: 12 A
Rated operational power at AC-3, 400 V: 5.5 kW
Rated operational power NEMA: 2.24 kW
Suitable for series installation: No
Number of auxiliary contacts as NC contacts: 1
Connection type main circuit: Screw connection
Number of NO contacts as main contacts: 3

Further details: Miniature contactors B/BC 6 and B/BC 7 of 4 and 5.5 kW AC-3 (400 V) represent a series with very small dimensions and with connection variants in screw, solder pin, and blade terminal technology. This and the wide range of contact and coil variants offer a very wide range of possible applications, even in unfavorable space conditions. With their AC or DC control, they switch power circuits with motors, slightly inductive, or non-inductive loads. Accessories that can be fitted include suppressors and 2-pole auxiliary switches that can be plugged in at the side or front.

Key specifications

Relay type
Power contactor
input voltage
24 V
Output voltage
690 V
Electric current output
20 A
Output current type
AC, DC
Number of poles
3x

General information

Item number
36799997
Manufacturer
ABB
Category
Relays
Manufacturer No.
GJL1317001R0011
Release date
28.6.2023

Relay properties

Relay type
Power contactor
input voltage
24 V
Output voltage
690 V
Electric current output
20 A
Output current type
AC, DC
Switching function
Normally open
Number of openers
1x
Number of closers
3x
Number of poles
3x
Max. Switching capacity
5.50 kW

Origin

Country of origin
China, Germany

Sustainability

Manufacturer commitment
RE100

Voluntary climate contribution

CO₂ emissions
29,26 kg
Climate contribution
EUR 0,74

Scope of delivery

Scope of delivery
1 pc.

Product dimensions

Length
140 mm
Width
120 mm
Height
50 mm
