The Intel NUC 12 Pro Kit NUC12WSHi7 is a powerful mini-PC barebone designed for a variety of applications. With a compact UCFF chassis, this system delivers excellent performance in a small form factor. It is equipped with an Intel Core i7-1260P processor, featuring 12 cores and 16 threads, which allows for efficient multitasking application processing. The NUC12WSHi7 supports up to 64 GB of DDR4 RAM and provides space for two storage slots that can be equipped with M.2 PCIe SSDs. The integrated Iris Xe Graphics enhances graphic performance, while the extensive connectivity options, including Thunderbolt 4 and HDMI, ensure flexible connectivity. This barebone system is ideal for users seeking a customizable and powerful solution for their computing needs.
Number of processor cores | 12 -Core |
Memory type | DDR4-RAM |
Graphics card model | Iris Xe Graphics |
Internal connection options | M.2 (2x) |
USB ports | Thunderbolt 4, USB-A |
Network connections | RJ45 (1x) |
Video connections | HDMI (2x) |
Item number | 23292009 |
Manufacturer | ASUS |
Category | Barebones |
Manufacturer no. | RNUC12WSHI70002 |
Release date | 1.12.2022 |
Processor type | Intel Core i7-1260P |
Clock frequency | 3.20 GHz |
Number of processors | 1x |
Number of processor cores | 12 -Core |
Number of threads | 16 |
Socket | BGA 1744 |
Max. turbo clock rate | 4.70 GHz |
Max. TDP | 35 W |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Max. memory slots | 2 |
Max. RAM | 64 GB |
Memory voltage | 1.20 V |
Graphics card model | Iris Xe Graphics |
Max. connected monitors | 4x |
Internal connection options | M.2 (2x) |
Data storage controller | Intel I225-V |
"Number of 2.5"" drive slots" | 1x |
USB ports | Thunderbolt 4, USB-A |
Exact USB ports | Thunderbolt 4 (2x), USB-A 3.1 Gen 1 (3x) |
Network connections | RJ45 (1x) |
Max. port speed | 1000 Mbit/s |
Connectivity | Bluetooth, WLAN |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Wi-fi frequency | 6 GHz |
Bluetooth version | 5.2 |
Video connections | HDMI (2x) |
Power | 120 W |
Country of origin | China |
Manufacturer commitment | RE100, SBTi |
Scope of delivery | Power cord |
Width | 112 mm |
Length | 117 mm |
Height | 54 mm |
Product Safety |
Length | 19.50 cm |
Width | 17.30 cm |
Height | 12.50 cm |
Weight | 1.66 kg |
How often does a product of this brand in the «Barebones» category have a defect within the first 24 months?
Source: GalaxusHow many working days on average does it take to process a warranty claim from when it arrives at the service centre until it’s back with the customer?
Source: GalaxusHow often is a product of this brand in the «Barebones» category returned?
Source: Galaxus
The NUC12WS impresses with high computing power in a compact design. The performance is sufficient not only for office work but also for image editing and occasional video editing. Thanks to the many interfaces, the computing dwarf can be flexibly expanded externally. Compared to a notebook, you get more computing power per euro and can choose the RAM and SSD capacity according to your own preferences...
