Primary rated voltage: 670V ac, 690V ac, 710V ac
Secondary rated voltage: 230V ac
Rated power: 100VA
Mounting type: Chassis
Number of outputs: 1
Length: 84mm
Width: 76mm
Depth: 95mm
Dimensions: 84 x 76 x 95mm
Operating frequency min: 50Hz
Operating frequency max: 60Hz
Temperature max: +40°C
Weight: 2.2kg

Switchboard primary 690 Vac (63/2500VA). Regulation with low inrush current peak, safety insulation, and isolating transformer. Screw terminals equipped with screw mounting brackets. Compact design with ±20 V taps on main winding. For use at maximum +40°C ambient temperature.
