Eaton Electric GmbH Power contactor DILM9-01(24V50HZ)
Only 1 piece in stock at supplier
Electric current output2
Product details
The Eaton power contactor DILM9-01 (24V50HZ) is a high-performance electrical switching device specifically designed for industrial applications. With a rated control supply voltage of 24 V at 50 Hz, this 3-pole power contactor is ideal for controlling motors and other electrical loads. It offers a high operating voltage of up to 690 V and is suitable for various applications, including non-inductive or lightly inductive loads as well as squirrel-cage motors. The robust construction and the use of screw terminals ensure a reliable connection and easy installation. The device is designed for use in demanding environments and meets the requirements of efficiency class IE3, making it an environmentally friendly choice. The DILM9-01 is a versatile and reliable product that can be used in many industrial applications.
- Suitable for motors of efficiency class IE3
- Operating power of up to 4 kW at 400 V
- Connection type via screw terminals for easy installation
- Number of main contacts: 3 normally open
- Operating voltage up to 690 V for versatile applications.
Relay type | Power contactor |
input voltage | 24 V |
Output voltage | 24 V |
Electric current output | 22 A |
Output current type | AC/DC |
Number of poles | 3x |
Item number | 20021477 |
Manufacturer | Eaton |
Category | Relays |
Manufacturer No. | 276712 |
Release date | 16.3.2022 |
Relay type | Power contactor |
input voltage | 24 V |
Output voltage | 24 V |
Electric current output | 22 A |
Output current type | AC/DC |
Switching function | Normally open |
Number of openers | 1x |
Number of closers | 3x |
Number of poles | 3x |
Max. Switching capacity | 4 kW |
Smart home | Not compatible |
Country of origin | China |
Manufacturer commitment | SBTi |
CO₂ emissions | 29,26 kg |
Climate contribution | EUR 0,74 |
Scope of delivery | 3-pole, AC-4: Squirrel cage motors: Starting, Application: Power contactors for motors, Connection technology: Screw terminals, Contactors up to 170 A, NAC-3: Squirrel cage motors: starting, Notes: Also suitable for motors of efficiency class IE3., Plug in, Power contactor, Resistance furnaces, Reverse, Switch off during operation, Tap, Utilisation category: AC-1: Non-inductive or slightly inductive loads |
Length | 68 mm |
Width | 45 mm |
Height | 68 mm |
