Gigabyte MB GBT Intel 1700 Z790 A ELITE AX ICE
LGA 1700, Intel Z790 Express, ATXPrice in EUR including VAT, free shipping
Product details
The Gigabyte Z790 Aorus Elite AX ICE is an ATX motherboard with the high-end Intel Z790 chipset and the LGA 1700 socket. The motherboard is suitable for desktop processors of the 12th, 13th and 14th generation
Intel Core CPUs, codenamed: Alder Lake and Raptor Lake. It supports DDR5 memory with up to 7,600 MHz and is ideal for overclocking thanks to its outstanding power supply.
In addition to a stable power supply with 16+1 phase VRMs, the GIGABYTE Z790 Aorus Elite AX ICE impresses with other features that make overclocking your system much easier. Buttons for CMOS reset and bios flashes as well as efficient VRM heat sinks specifically improve your OC experience.
In addition to a stable power supply with 16+1 phase VRMs, the GIGABYTE Z790 Aorus Elite AX ICE impresses with other features that make overclocking your system much easier. Buttons for CMOS reset and bios flashes as well as efficient VRM heat sinks specifically improve your OC experience.
| Processor family | Celeron, Core i3, Core i5, Core i7, Core i9 |
| Memory type | DDR5 RAM |
| Internal connection options | 24-pin ATX power connector (1x), 4-pin CPU (2x), 8-pin EPS (2x), M.2 PCI/SATA Combo (1x), M.2 PCIe (4x), S-ATA III (6x), TPM Header, USB 2.0 Header (2x), USB 3.0 Header (1x) |
| Wireless transmission | Bluetooth, Wi-Fi |
| Peripheral connections | USB 2.0 Type-A (4x), USB 3.2 Gen 1 (3.1 Gen 1) Type-A (3x), USB 3.2 Gen 1 (3.1 Gen 1) Type-C (1x) |
| Item number | 38933397 |
| Manufacturer | |
| Category | |
| Manufacturer no. | Z790 A ELITE AX ICE |
| Release date | 27.9.2023 |
| Sales rank in Category Motherboards | |
| Maximum order quantity | 25 |
| Form factor | ATX |
| Processor socket | LGA 1700 |
| Chipset | Intel Z790 Express |
| Mainboard features | Clear CMOS Button, Trusted Platform Module |
| Operating system compatibility | Windows, Windows 10 |
| Peripheral connections | USB 2.0 Type-A (4x), USB 3.2 Gen 1 (3.1 Gen 1) Type-A (3x), USB 3.2 Gen 1 (3.1 Gen 1) Type-C (1x) |
| BIOS type | UEFI AMI |
| Wireless transmission | Bluetooth, Wi-Fi |
| Wi-Fi standard | Wi-Fi 6 / 802.11ax |
| Processor type | Intel Core i3 |
| Processor family | Celeron, Core i3, Core i5, Core i7, Core i9 |
| Memory form factor | DIMM |
| Number of memory modules (RAM) | 4 x |
| Max. memory (RAM) | 192 GB |
| Memory chip | DDR5 SDRAM |
| Max. RAM OC | 7600 MHz |
| Supported memory speed | 4000 MHz, 4800 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz, 6000 MHz, 6200 MHz, 6400 MHz, 6600 MHz |
| Memory type | DDR5 RAM |
| RAM buffer | Unbuffered |
| Channel architecture | 2 |
| Video connections | DisplayPort (1x) |
| Video connection version | Display port 1.2, HDMI 2.0 |
| Network connections | RJ45 2.5 Gigabit Ethernet (1x) |
| Max. port speed | 2.50 Gbit/s |
| Audio channel | 7.1 Channel |
| Audio Connections | Headphone output (2x), Microphone |
| Internal connection options | 24-pin ATX power connector (1x), 4-pin CPU (2x), 8-pin EPS (2x), M.2 PCI/SATA Combo (1x), M.2 PCIe (4x), S-ATA III (6x), TPM Header, USB 2.0 Header (2x), USB 3.0 Header (1x) |
| Expansion slot | PCI Express x16 (1x), PCI Express x16 (3x), PCI Express x4 (1x) |
| PCI express version (max.) | 5 |
| Power connectors | 8-pin PCI-E |
| Country of origin | China |
| Scope of delivery | Norton Internet Security, SATA cable |
| Length | 244 mm |
| Width | 305 mm |
| Height | 35 mm |
| Weight | 2300 g |
| Length | 34.20 cm |
| Width | 30.90 cm |
| Height | 8.80 cm |
| Weight | 2.01 kg |
