Merten Push Button Switch Insert 2p. 318501

Manufacturer: Merten
Description: Push Button Switch Insert 2p. Roller Latching Switch
Type: 318501
Configuration: Flush-mounted Insert
Design: 2-pole Push Latching Switch
Number of Poles: 2
Operation Type: Key
Mechanically Operable: Yes
Electronically Operable: No
Mounting Type: Flush Mount
Material: Metal/Plastic
Material Quality: Other
Halogen-free: Yes
Mounting Method: Claw/Screw Mounting
Transparent: No
Text Field/Label Area: No
Suitable for Protection Class (IP): IP20
Rated Current: 10 A
Nominal Voltage: 250 V
Minimum Depth of Device Box: 46 mm

Merten Push Button Switch Insert 2p. 318501: Additional Details
For standardized profile half-cylinder locks with a length of 40 mm. To be completed with central plate for roller shutter push latching switch inserts System M 3194xx, 3193xx, System Design MEG3883-60xx, AQUADESIGN 3482xx. Accessories include profile half-cylinder with key withdrawal in the middle position MEG3985-0001. Profile half-cylinder with key withdrawal in 3 positions MEG3985-0003.
Scope of Delivery: Without lock.
Design: 2-pole.
EAN: 4011281579303.
