Saft Battery LS33600 with solder tag Z-shape

1 pcs., D, 1700 mAh
Ratings
Currently out of stock

Product details

Saft LS33600 lithium thionyl chloride disposable battery

3.6V primary lithium-thionyl chloride (Li-SOCl2) size - R20 - D - Mono

  • With soldering lug in Z-shape
  • High and stable operating voltage
  • Low self-discharge rate (less than 1% after 1 year of storage at +20°C)
  • Stainless steel container, hermetic glass-to-metal sealing
  • Built-in safety vent, finish with or without flat positive end
  • Non-flammable electrolyte, compliant with IEC 86-4 safety standard and EN 50020 intrinsic safety standard
  • Underwriters Laboratories (UL) component recognition (File Number MH 12609)
  • Restricted for transport (Class 9)
  • For applications requiring good voltage response and operating life in -60°C to +85°C environments

Warning:

  • Fire, explosion, and severe burn hazard.
  • Do not recharge, short circuit, crush, disassemble, heat above 100°C (212°F), incinerate, or expose contents to water.
  • Do not solder directly to the cell.

Main applications: Radiocommunication and other military applications, alarms and security systems, beacons and emergency location transmitters, GPS, metering systems, sonobuoys, micropipettes.

Technical data Saft LS33600:

  • System: Primary lithium-thionyl chloride (Li-SOCl2) (non-rechargeable)
  • Connection type: With solder tags
  • Voltage: 3.6 Volt
  • Capacity: 17000mAh
  • Dimensions (DxH): 61x33mm
  • Size: D/Mono
  • Weight: 90 grams.

Key specifications

Items per sales unit
1 pcs.
Battery type
Li-SOCI2
Voltage
3.60 V
Item number
12503733

General information

Manufacturer
Saft
Category
Batteries
Release date
10.1.2020

Battery properties

Battery size
D / LR20 / Mono / R20
Voltage
3.60 V
Battery type
Li-SOCI2
Battery capacity
1700 mAh
Rechargeable
No

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Weight
90 g

Ingredients and instructions for use

Ingredients
Saft LS33600 Lithium Thionyl Chloride disposable battery3.6V Primary lithium-thionyl chloride (Li-SOCl2) Size - R20 -D -Mono with solder tag in Z-shape High and stable operating voltage Low self-discharge rate (less than 1% after 1 year of storage at + 20°C) Stainless steel container, Hermetic glass-to-metal sealing Built-in safety vent, Finish with or without flat positive end Non-flammable electrolyte, Compliant with IEC 86-4 safety standard and EN 50020 intrinsic safety standard Underwriters Laboratories (UL) Component Recognition (File Number MH 12609) Restricted for transport (Class 9) For applications requesting good voltage response and operating life in -60°C/+ 85°C environments. Warning - Fire, explosion and severe burn hazard. - Do not recharge, short circuit, crush, disassemble, heat above 100°C (212°F), incinerate, or expose contents to water. - Do not solder directly to the cell.Main applications: Radiocommunication and other military applications, Alarms and security systems, Beacons and emergency location, transmitters, GPS, Metering systems, Sonobuoys, Micropipettes . Technical data Saft LS 33600: System: Primary lithium-thionyl chloride (Li-SOCl2) (Not rechargeable)Connection type: with solder lugs, Voltage: 3.6 Volt, Capacity: 17000mAhDimensions (DxH): 61x33mm, Size: D/Mono, Weight: 90Gramm.
