Schneider Electric Pushbutton, compl., momentary, green, with XB5AP31C0

Price in EUR including VAT
Delivered between 12.1.2027 and 26.1.2027
Free shipping on orders over 30,–

In Detail

Schneider Electric Push Button Complete XB5AP31C0

Manufacturer: Schneider Electric
Description: Complete push button, 22mm, 1NO, gray
Type: XB5AP31C0
Number of command points: 1
Button shape: high
Button color: green
Lens shape: round
Hole diameter: 22.5 mm
Suitable for lighting: no
Latching switch function: no
Momentary: yes
Supply voltage of the lamp: 0 V
Number of contacts as normally open: 1
Electrical connection type: screw connection
With front ring: yes
Material of front ring: plastic
Front ring color: black
Protection class (IP): IP66
Protection class (NEMA): other

Plastic push button with silicone protective cap as a complete device and 22mm installation size, Harmony XB5 series. The color of the push button is green. With 1 normally open contact. The color of the outer ring is gray. The actuation function is non-latching. The modular Harmony series with 22mm installation size combines easy installation, efficiency, modern design, and flexibility with maximum robustness. IP protection classes up to IP69K and ambient temperatures from -40°C to +70°C. Product standards according to EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 No 14, UL 508, EN/IEC 60947-1, JIS C 4520. Certifications according to DNV, GL, UL listed, RINA, BV, CSA, LROS (Lloyds Register of Shipping).
