Schneider Electric Pilot Light Selector XB4BK123G5

Manufacturer: Schneider Electric
Description: Green pilot light selector 1S+1Ö 120V
Type: XB4BK123G5
Number of switching positions: 2
Actuating element design: short rotary knob
Suitable for lighting: yes
With light source: yes
Button color: green
Hole diameter: 22.5 mm
Switching function latching: yes
Pushbutton: no
Protection class (IP): IP66
Protection class (NEMA): 13
Supply voltage: 110..120 V
Number of contacts as normally closed: 1
Number of contacts as normally open: 1
Electrical connection design: screw connection
With front ring: yes
Material of front ring: metal
Color of front ring: chrome

Schneider Electric Pilot Light Selector XB4BK123G5: additional details
The Harmony XB4 series made of metal offers a wide range of 22mm complete devices such as push buttons, pilot lights, and selectors, as well as emergency stop switches. Additionally, due to the modular design of the devices, all components can also be obtained as individual elements, and optionally for 30mm installation size. Due to their quality, flexibility, and extreme robustness (protection classes up to IP69K), these devices are ideal for most applications in industry and buildings. This pilot light selector in green includes a universal LED and requires a supply voltage of 120V AC. The switch features 2 positions along with 1 normally closed and 1 normally open contact. Installed in a 22mm hole, the device is connected via screw terminals on the back of the product. Due to the variety of existing product standards and certifications, it is suitable for international use. Thanks to the Green Premium environmental label, you can obtain detailed information on material contents, environmental impacts, and circular economy that support your sustainability goals.
