Siemens Digital Industries SIMATIC S7-1200 6ES7222-1AD30-0XB0

Manufacturer: Siemens Digital Industries
Designation: SIMATIC S7-1200 4DQ, 5VDC 200KHz
Type: 6ES7222-1AD30-0XB0
Supply voltage at AC 50 Hz: 0 V
Supply voltage at AC 60 Hz: 0 V
Supply voltage at DC: 24 V
Type of supply voltage: DC
Number of digital outputs: 4
Configurable digital inputs: yes
Configurable digital outputs: yes
Type of digital output: Transistor
Output current: 0.1 A
Permissible voltage at output: 4.25..6 V
Type of output voltage: DC
Short circuit protection for outputs: no
Redundancy capability: no
Type of electrical connection: Screw/spring connection
Suitable for safety functions: no
Associated operating equipment (Ex ia): no
Associated operating equipment (Ex ib): no
Explosion protection category for gas: ATEX Gas-Ex protection, Cat. 3G
Explosion protection category for dust: none
Width: 38 mm
Height: 62 mm
Depth: 21 mm

Siemens Digital Industries SIMATIC S7-1200 6ES7222-1AD30-0XB0: additional details
SIMATIC S7-1200, Digital Output SB 1222, 4DQ, 5V DC 200kHz
SIMATIC S7-1200 Basic Controller - flexible with a variety of communication options. If you only need to expand your SIMATIC S7-1200 CPU by a few inputs or outputs, signal boards are a good alternative to signal modules. Signal boards are directly plugged onto the front of the controller (also possible with CPU 1211C) and are available as digital and analog input, output, and mixed modules. A communication board with RS 485 interface is also available. Signal boards thus allow for subsequent configuration expansion without additional space requirements in the control cabinet.
