Weidmüller Coupling relay 5 V/DC 6 A

Minimum order 10
Price in EUR including VAT
Ratings
BrandMore from Weidmüller
Delivered between Thu, 23.10. and Thu, 30.10.
free shipping

Product details

The Weidmüller coupling relay is a reliable switching relay designed for a variety of applications in automation technology. It provides galvanic isolation between the control and load circuits, enabling safe and efficient control. With a coil voltage of 5 V DC and a maximum switching capacity of 1.5 kVA, this relay can switch both AC and DC loads up to 6 A. It can be easily mounted on a DIN rail, facilitating integration into existing systems. The relay is equipped with screw terminals that ensure a reliable connection. With an IP20 protection rating, it is suitable for use in protected environments.

  • Galvanically isolated control and load circuits
  • Maximum switching capacity of 1.5 kVA
  • Easy mounting on DIN rail
  • Screw terminals for reliable connections
  • Contact material made of AgNi for high reliability.

Key specifications

input voltage
5 V
Scope of delivery
1 changeover contact Complete modules consisting of a relay and a base with AC/DC/UC coils with screw connection, Relay coupler
Output voltage
250 V
Output current type
DC
Electric current output
6 A
Relay type
Switching relay
Item number
8432570

General information

Manufacturer
Weidmüller
Category
Relays
Manufacturer no.
1122740000
Release date
20.4.2018
Minimum order
10
Order quantity steps
10

Relay properties

Relay type
Switching relay
input voltage
5 V
Output voltage
250 V
Electric current output
6 A
Output current type
DC
Resistor
1.50 Ω (ohm)
Switching function
Changer
Number of openers
1 x
Number of closers
1 x
Number of poles
1 x
Number of switching cycles
50000 x
Max. Switching capacity
1.50 kW
Manufacturer Type
TRS 5VDC 1CO

Smart home features

Smart Home
Not compatible

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
1 changeover contact Complete modules consisting of a relay and a base with AC/DC/UC coils with screw connection, Relay coupler

Product dimensions

Length
70 mm
Width
6.40 mm
Height
90 mm
Weight
33 g
