Accuride Ball linear guide DA0115-RCH
Price in EUR including VAT
Delivered between Thu, 2.7. and Sat, 4.7.
Only 4 pieces in stock at supplier
Only 4 pieces in stock at supplier
Free shipping starting at 30,–
Length3
Product details
The DA0115-RCH ball linear guide from Accuride is a heavy-duty drawer slide solution suitable for a wide range of applications. With a maximum load capacity of up to 130 kg, it provides reliable and stable support for heavy drawers. The rails are made of corrosion-resistant aluminum, enhancing their durability and resilience. The ball recirculation carriages are made of plastic and can be equipped with either stainless steel or plastic balls, allowing for flexible adaptation to different requirements. The rails can be individually cut to the desired length, and installation is done through holes with a diameter of 4.2 mm. This functionality makes the ball linear guide particularly versatile and customizable for various projects.
- Maximum load capacity of up to 130 kg
- Corrosion-resistant aluminum construction
- Customizable rail lengths
- Built-in soft-close mechanism for gentle closing.
Exact colour description | Grey |
Material | Aluminium |
Extension type | Ball pull-out |
Max. load | 130 kg |
Items per sales unit | 1 pcs. |
Length | 178 mm |
Item number | 13944777 |
Manufacturer | Accuride |
Category | Drawer runners |
Manufacturer No. | DP0115-ECRC-2 |
Release date | 6.10.2020 |
Colour | Grey |
Exact colour description | Grey |
Material group | Metal |
Material | Aluminium |
Extension type | Ball pull-out |
Closing function | Steamed |
Max. load | 130 kg |
mounting style | Floor mounting, Flying |
borehole diameter | 4.20 mm |
Country of origin | China |
CO₂ emissions | 6,38 kg |
Climate contribution | EUR 0,15 |
Items per sales unit | 1 pcs. |
Length | 178 mm |
Width | 46 mm |
Height | 14 mm |
Diameter | 38 mm |
